High Tonnage Hydraulic Cylinder, 3036 kN, 50 mm Stroke - Enerpac HCG3002

Delivering 3036 kN of force across a 50 mm stroke, the HCG3002 handles demanding lifting and pressing jobs at high load. As a single-acting high-tonnage cylinder with a hardened plunger surface, it is built for cyclic duty in plant and machinery work.

Benefits

• Hardened plunger surface resists side loading and cyclic wear
• 10 % side-load resistance across the full cylinder capacity
• Stop-ring prevents plunger blow-out at the end of the stroke
• Weather protected for use indoors and outdoors
• Upper and lower replaceable bearings guide the plunger throughout the stroke
• Certified lifting eyes and base mounting holes for safe handling and installation
• Optional collar thread (suffix E002) available on 300 ton and higher capacities

Technical data

• Force: 3036 kN
• Stroke: 50 mm
• Action: single-acting
• Operating pressure: 700 bar
• Weight: 158 kg
• Series: HCG

Applications

Suited to lifting, pressing and positioning tasks with high force demand in structural steel and plant work, machine installation and structural load transfer. Operate with 700 bar hydraulic power units and matching high-pressure hoses.
