Galvanized steel flange plate for ISO 15552 front mounting of pneumatic cylinders with a 160 mm piston diameter. The scope of supply includes the flange plate and 4 fixing screws, so installation needs no extra parts.
Flange Mounting ISO 15552, Piston Ø 160 mm - Airtec TB 160
AIRTEC Original product
Net price (excl. VAT)
€154.22 €129.60
Item FL-TB-160
Manufacturer no. TB 160
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.TB 160
EAN4050571689261
Customs tariff number84129080
ConditionNew
Artikel
FL-TB-160
The Airtec TB 160 is a flange mounting to ISO 15552 for pneumatic cylinders with a 160 mm piston diameter. The flange plate is bolted to the cylinder end face and transfers the piston force over a wide area into the mating structure.
Benefits
- Standard-compliant mounting to ISO 15552 for dimensional interchangeability
- Galvanized steel material for corrosion protection and high load capacity
- Exact fit for cylinders with a 160 mm piston diameter
- Ready to install with 4 fixing screws included
- End-face flange mounting for smooth force transmission
Technical data
| Material | galvanized steel |
| Standard | ISO 15552 |
| for piston diameter | 160 mm |
| B | 18 mm |
| D | 20 mm |
| L | 280 mm |
| M | 180 mm |
| N | 140.0 mm |
| T | 230 mm |
| TM | 115 mm |
| U | 260 mm |
| Scope of supply | 1 flange plate incl. 4 fixing screws |
| Weight | 6 kg |
Applications
For end-face mounting of ISO 15552 profile cylinders in machines and automation systems, wherever the cylinder force is to be supported through a front flange.
| Hersteller-Nr | TB 160 |
|---|---|
| Manufacturer | Airtec |
| EAN | 4050571689261 |
| Weight | 6.000000 |
| Zolltarifnummer | 84129080 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
