Pivoting angled fitting, M10x1.0 o., Pipe exterior Ø 8 - Riegler 158839

Pivoting angled fitting, M10x1.0 o., Pipe exterior Ø 8 mm, a/f1 14, a/f2 14, Operating pressure max. 100 bar, galvanised steel Banjo elbow, metric male thread with O-ring, very light type

Technical data

Standards and origin

• Customs tariff number: 73079910
• Country of origin: IT

About Banjo elbows

A swivel elbow fitting turns the pipe run through 90 degrees and can be aimed in the outlet direction without opening the sealing point. The range connects tubes from 4 to 28 mm outside diameter and is rated for nominal pressures of 100 to 400 bar.

What matters when choosing

• Tube outside diameter from 4 to 28 mm defines the cutting ring and the nut and has to match the installed tube exactly.
• Nominal pressure PN runs from 100 to 400 bar and falls as tube diameter grows, so check the figure for the specific size.
• Threads come in BSP versions from G 1/8 to G 1/2 male and metric versions from M8x1.0 to M33x2.0 male.
• Material is zinc-plated steel to DIN 2353 for the high pressure versions or nickel-plated brass for the versions limited to 60 bar operating pressure.
• Spanner sizes SW 1 and SW 2 together with lengths L1 and L2 show how much room assembly and tooling require.

Typical applications

• Hydraulic power units where the line direction is fixed only during installation.
• Connecting cylinders and valve blocks in machine tools and presses.
• Lubrication and control lines with tube diameters from 4 mm upwards.
• Compressed air and water lines in the brass version up to 60 bar.
• Rework on existing pipe runs where the elbow position has to be corrected afterwards.

The steel versions are zinc-plated and follow DIN 2353, with nickel-plated brass available alongside. The 44 articles in this group come from Italy and Germany.
