Push-in T-fitting »Blue Series«, L-shape, rotating, G 1/2 o. - Riegler 109539

Push-in T-fitting »Blue Series«, L-shape, rotating, G 1/2 o., for hose exterior Ø 6 mm, pmax short term 15 bar Push-in fittings series manufactured in plastic and nickel-plated brass. All parts are suitable for use with hoses, tubes or pipes made of plastic.

Technical data

Standards and origin

• Customs tariff number: 39174000
• Country of origin: CN

About Male branch tees

A push-in T-fitting takes a second outlet directly out of a running compressed air line, so no separate manifold is needed. The tube is pushed in without tools and released via the release ring. The range covers tube outside diameters from 3 to 16 mm at working pressures of 10 to 20 bar.

What matters when choosing

• Pick the thread to match the port. Parallel G threads run from G 1/8 to G 1/2, tapered R threads from R 1/8 to R 1/2, with M3, M5 and M6 available for small valve and cylinder ports.
• The tube O.D. follows the line, not the thread. Sizes from 3 to 16 mm are covered and most thread and diameter combinations are available.
• Material depends on the surroundings. Plastic with nickel-plated brass is the standard build, all nickel-plated brass the fully metallic version, stainless steel 1.4404 the choice for corrosive atmospheres.
• The sealant follows the medium. NBR covers plain compressed air, FKM or FPM suits higher temperatures and oil-bearing media, and the FDA-compliant FKM version is intended for food contact applications.
• Operating temperature starts at -20 °C and ends either at 80 °C or at 150 °C depending on the version. Above 80 °C, check the data table of the individual article.

Typical applications

• Branching the air supply to two cylinders working in parallel on an assembly fixture
• Tapping off a pressure switch or gauge from a continuous line
• Building distribution runs and ring mains along the machine frame
• Linking closely spaced valve ports with M5 threads in tight installation space
• Connecting blow guns and blow-off nozzles to an existing supply line

Threads are made to DIN EN ISO 228-1, ISO 7-1 and DIN 13-1. Besides the Blue Series and Blue Series mini, the inox line, click-clock, metallica, universal short and NonPlusUltra ranges are available, 344 articles in total.
