Flat suction cup, round, Silicone material, »PFG« - Riegler 108458

Flat suction cup, round, Silicone material, »PFG«, ø:80 suitable connection nipple IT/ET M10x1.25 / G 1/4 Robust and hard-wearing suction pad with a single sealing lip. Used wherever objects (parts, packing materials, etc.) need to be lifted, transported, turned over or handled in some other manner. It is also ideal when it is necessary to handle smooth or slightly rough surfaces. Due to its flat shape, it can grip the workpiece in a very short time and withstand the forces that result from fast movement of the object during handling. It acts as the connecting element between the vacuum generator and the workpiece. Properties: Very short evacuation timesSuitable for high lateral forcesGood intrinsic stability when attached to the loadSupports on the bottomVery short cycle timesHigh suction forces with small dimensions Applications: Handling workpieces with smooth or slightly rough surfaces, e.g. metal sheets, cardboard boxes, sheets of glass, plastic parts and sheets of wood.

Technical data

Standards and origin

• Customs tariff number: 39269097
• Country of origin: IN

About Suction pads

Suction cups form the contact with the workpiece in a vacuum system and decide how securely it is held. The series runs from 3.5 mm to 50 mm diameter, covering small components as well as cartons and sheet metal blanks.

What matters when choosing

• Diameter comes first. Available sizes are 3.5 / 5 / 8 / 10 / 14 / 15 / 20 / 25 / 30 / 35 / 40 and 50 mm, chosen from the weight and the contact area of the part.
• The shape follows the surface. Bellows cups with folds absorb height differences and curved faces, flat cups hold even parts in a precise position.
• The connection thread has to match the nipple or the bracket. The group covers M3 male, M5 male and female, G 1/8 male and female, and G 1/4 male and female.
• Cup height lies between 2 and 23 mm and has to be allowed for in the stroke of the axis when the gripper sets down on the part.
• Holding force, break-away force and the minimum convex workpiece radius are listed per item and should be checked against the heaviest part to be handled.

Typical applications

• Handling cartons and packaging in packaging machinery
• Picking sheet metal blanks at presses and stamping lines
• Placing and transferring small components in assembly
• Handling films, labels and paper sheets
• Palletising and restacking at the end of the line

The group holds 98 items with diameters from 3.5 to 50 mm. The matching connection nipple with male or female thread and the recommended hose diameter are listed for each cup.
