309 kN Capacity, 29 mm Stroke, Low Height Multi-stage, Telescopic Hydraulic Cylinder - Enerpac RLT311
Datasheet (PDF)
Pictures are for reference and may not be accurate, actual product may differ
RLT311, 309 kN Capacity, 29 mm Stroke, Low Height Multi-stage, Telescopic Hydraulic Cylinder

309 kN Capacity, 29 mm Stroke, Low Height Multi-stage, Telescopic Hydraulic Cylinder - Enerpac RLT311

ENERPAC Original product
Net price (excl. VAT)
€1,973.42 €1,658.34
excl. Shipping Cost
Available Fast shipping
Item ENP-RLT311
Manufacturer no. RLT311
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.RLT311
Country of originUnited States
ConditionNeu
Add to Wish List Add to Compare
Artikel
ENP-RLT311
Model: RLT311 |ECCN: EAR99 | Harmonization: 8412210045
Series: RLT |Product Line: Industrial Tools

  • Single-Acting, load return
  • Nitrocarburization surface treatment for improved wear resistance and corrosion protection for increased safety and longer service life in harsh conditions.
  • The longer stroke length of telescopic cylinders will save you time and simplify projects by moving a load a greater distance and eliminating the use of temporary cribbing.
  • For use in confined spaces: machinery positioning, tool fastening
  • Mounting bolt holes for easy fixing
  • Up to 3% side-load of maximum capacity
  • Design safety factor complies with ASME B30.1 & EN1494
  • CR400 coupler for compatibility with standard product
  • High-Alloy steel for maximum strength
  • 1st Stage: maximum load capacity at lower stroke.
  • 2nd Stage: extended stroke with lower capacity than the 1st stage.
  • Final Stage: maximum stroke extension with lowest capacity.

Dimension imperial

Collapsed Height A (in)
3.50
Extended Height B (in)
4.65
Outside Diameter D (in)
6.50 x 5.51
Dimension D1 (in)
6.50
Diameter D2 (in)
5.51
Base to Advance Port H (in)
0.98
Plunger to Base L (in)
2.78
Plunger to Mounting Hole M (in)
2.60
Base Mounting Hole Pitch U (in)
2.99
Base Mounting Hole Diameter V (in)
0.51
Base Mounting Hole Counter Bore Diameter (in)
0.79
Base Mounting Hole Counter Bore Depth (in)
0.51

Dimension metric

Collapsed Height A (mm)
89
Extended Height B (mm)
118
Outside Diameter D (mm)
165 x 140
Dimension D1 (mm)
165
Diameter D2 (mm)
140
Plunger Diameter F (mm)
60
Base to Advance Port H (mm)
25
Plunger To Base L (mm)
70,5
Plunger To Mounting Hole M (mm)
66
Base Mounting Hole Pitch U (mm)
76
Base Mounting Hole Diameter V (mm)
13
Base Mounting Hole Counter Bore Diameter (mm)
20
Base Mounting Hole Counter Bore Depth (mm)
13
More Information
Hersteller-Nr RLT311
Manufacturer Enerpac
Country of Manufacture United States
Weight 13.000000
Hinweis Industriewerkzeuge
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Originalprodukt
Artikelzustand Neu
