P-R-S manifold rail with 12 stations for M04 / P04 series valves, supplied with hollow bolts and seals. Central air supply via G 1/4", valve ports G 1/8". Unused stations closed with R 283/V.
P-R-S Manifold Rail 12 Stations, Valve Series M04/P04 - Airtec R 283/12
AIRTEC Original product
Net price (excl. VAT)
€197.80 €166.22
Item FL-R-283/12
Manufacturer no. R 283/12
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.R 283/12
EAN4050571567859
Customs tariff number84812090
ConditionNeu
Artikel
FL-R-283/12
The Airtec P-R-S manifold rail links up to 12 valves of the M04 / P04 series on a single base with central compressed-air supply and exhaust. It ships complete with hollow bolts and seals, so it is ready to mount without extra parts.
Benefits
- 12 valve stations on one rail cut piping and installation space.
- Supplied with hollow bolts and seals, ready to install out of the box.
- Central air supply through G 1/4", valve ports through G 1/8".
- Unused stations can be closed off with the R 283/V blanking plate.
- Replacement hollow bolts H 283 available separately.
Technical data
| Type | P-R-S manifold rail incl. hollow bolts and seals |
| Number of stations | 12 |
| For valve series | M04 / P04 |
| Matching blanking plate for empty station | R 283/V |
| Matching replacement hollow bolts | H 283 |
| A | M 5 |
| B | 20 mm |
| C | 5 mm |
| E | 6 mm |
| F | 25 mm |
| G | G 1/8" |
| H | 22.20 mm |
| I | 6 mm |
| J | 32 mm |
| K | 50 mm |
| L | G 1/4" |
| M | 32 mm |
| SW | 14 mm |
| Weight | 0.85 kg |
Applications
Central valve blocks in machine and plant control systems where several solenoid or pneumatic valves of the M04 / P04 series are grouped compactly and supplied with compressed air together.
| Hersteller-Nr | R 283/12 |
|---|---|
| Manufacturer | Airtec |
| EAN | 4050571567859 |
| Weight | 0.850000 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikel-Authentizität | Originalprodukt |
| Artikelzustand | Neu |
