Pump-per-Point Synchronous Lifting System, 7.5 kW, 380 V - Enerpac EVOP140150W

The EVOP synchronous lifting system drives each lifting point with its own pump, keeping multiple high-tonnage cylinders synchronised to 1.0 mm at up to 700 bar. Variable frequency motor control at 7.5 kW lifts level regardless of load distribution.

Benefits

• One pump per lifting point combines high flow rate with tight accuracy
• Up to 8x lifting speed compared with traditional multi-point systems
• Variable frequency drive (VFD) on the motor for smooth, stall-free operation
• Accuracy of 1.0 mm between leading and lagging cylinders
• Built-in warning and stop alarms for safe operation

Technical data

• Motor power: 7.5 kW
• Voltage: 380 V
• Operating pressure: 700 bar
• Synchronisation accuracy: 1.0 mm
• Dimensions: 1368 x 1250 x 805 mm
• Weight: 490 kg
• Series: EVOP

Applications

Designed for synchronous lifting of high-tonnage cylinders from 300 to 1000 t, including long-stroke lifts and repetitive sequences such as climbing-jack systems.
