€255.07
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-557911
Manufacturer Nr.
DW-80-100-Y-A
Hinge cylinder
Frequently Bought Together
-
This Item:
€255.07Excl. 19% VAT , excl. Shipping Cost
-
Festo 549746. Hinge cylinder DWA-50-125-Y-AB
€142.74Excl. 19% VAT , excl. Shipping Cost
-
Festo 558115. Hinge cylinder DWC-63-125-Y-AB
€159.02Excl. 19% VAT , excl. Shipping Cost
Total price
Stroke | 100 mm |
Piston diameter | 80 mm |
Piston rod thread | M20x1.5 |
Broad rod clevis/swivel mounting | 28 mm |
Cushioning | Pneumatic cushioning, adjustable at both ends |
Mounting position | optional |
Design | Piston Piston rod with rod clevis Swivel mounting on bearing cap Cylinder barrel |
Speed regulation | Integrated flow control at both ends |
Position detection | Via proximity switch |
Piston-rod end | Male thread with rod clevis |
Operating pressure | 1 bar ... 10 bar |
Mode of operation | Double-acting |
Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
Corrosion resistance class CRC | 0 - No corrosion stress |
LABS (PWIS) conformity | VDMA24364-B2-L |
Ambient temperature | -10 °C ... 60 °C |
Impact energy in end positions | 1.8 J |
Cushioning length | 30 mm |
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 2721 N |
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 3016 N |
Moving mass for 0 mm stroke | 1651 g |
Additional moving mass per 10 mm stroke | 39 g |
Basic weight for 0 mm stroke | 4185 g |
Additional weight per 10 mm stroke | 65 g |
alternative connections | See product drawing |
Type of mounting | Via swivel mounting on bearing cap With accessories |
Pneumatic connection | Rc3/8 |
Material rod clevis | Cast steel Tempered steel |
Note on materials | RoHS-compliant |
Material wiper | Bronze |
Material cover | Die-cast aluminium Anodised |
Material seals | NBR |
Material piston rod | Tempered steel Hard-chrome-plated |
Material cylinder barrel | Wrought aluminium alloy Anodised |
Manufacturer Nr. | DW-80-100-Y-A |
---|---|
Manufacturer | Festo |
EAN | 4052568204112 |
Weight | 3.900000 |
HS-Code | 84123100 |
