€2.53
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-132914
Manufacturer Nr.
QSM-M3-3-I-R-100
Push-in fitting
Festo 132914. Push-in fitting QSM-M3-3-I-R-100 is available to buy in increments of 100
Frequently Bought Together
-
This Item:
€2.53Excl. 19% VAT , excl. Shipping Cost
-
Festo 186354. Push-in L-fitting, long QSMLL-M7-4
€5.60Excl. 19% VAT , excl. Shipping Cost
-
Festo 130769. Push-in L-fitting QSML-M3-4-100
€3.65Excl. 19% VAT , excl. Shipping Cost
Total price
Size | Mini |
Nominal size | 1.6 mm |
Type of seal on screwed plug | Sealing ring |
Mounting position | optional |
Design | Straight design, round releasing ring |
Size of pack | 100 |
Design | Push-pull principle |
Operating pressure complete temperature range | -0.095 MPa ... 0.6 MPa |
Operating pressure complete temperature range | -0.95 bar ... 6 bar |
Operating pressure complete temperature range | -13.775 psi ... 87 psi |
Temperature-dependent operating pressure | -0.095 MPa ... 1.4 MPa |
Temperature-dependent operating pressure | -0.95 bar ... 14 bar |
Temperature-dependent operating pressure | -13.775 psi ... 203 psi |
Maritime classification | See certificate |
Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
Note on operating and pilot medium | Lubricated operation possible |
Corrosion resistance class CRC | 1 - Low corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Ambient temperature | -10 °C ... 80 °C |
Nominal torque | 0.48 Nm |
Tolerance for nominal tightening torque | ± 55% |
Product weight | 2.3 g |
Type of mounting | Internal hexagon, A/F 1.5 mm |
Pneumatic connection, port 1 | Male thread M3 |
Pneumatic connection, port 2 | For tubing outer diameter of 3 mm |
Colour of release ring | Blue |
Note on materials | RoHS-compliant |
Material housing | Nickel-plated steel |
Material release ring | POM |
Material tubing seal | NBR |
Material tubing clamp component | High-alloy stainless steel |
Manufacturer Nr. | QSM-M3-3-I-R-100 |
---|---|
Manufacturer | Festo |
EAN | 4052568028503 |
Weight | 0.001100 |
HS-Code | 74122000 |
