€125.42
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-559322
Manufacturer Nr.
DSNU-50-200-PPS-A
Round cylinder
Frequently Bought Together
-
This Item:
€125.42Excl. 19% VAT , excl. Shipping Cost
-
Festo 559321. Round cylinder DSNU-50-160-PPS-A
€122.38Excl. 19% VAT , excl. Shipping Cost
-
Festo 19265. ISO cylinder ESNU-16-50-P-A
€50.82Excl. 19% VAT , excl. Shipping Cost
Total price
Stroke | 200 mm |
Piston diameter | 50 mm |
Piston rod thread | M16x1.5 |
Cushioning | Self-adjusting pneumatic end-position cushioning |
Mounting position | optional |
Design | Piston Piston rod Cylinder barrel |
Position detection | Via proximity switch |
Symbol | 00992970 |
Operating pressure | 0.1 MPa ... 1 MPa |
Operating pressure | 1 bar ... 10 bar |
Mode of operation | Double-acting |
Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
Corrosion resistance class CRC | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Ambient temperature | -20 °C ... 80 °C |
Cushioning length | 20 mm |
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 989.6 N |
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 1178.1 N |
Moving mass | 913 g |
Product weight | 1887 g |
Type of mounting | With accessories |
Pneumatic connection | G1/4 |
Note on materials | RoHS-compliant |
Material cover | Wrought aluminium alloy |
Material seals | NBR TPE-U(PU) |
Material piston rod | High-alloy steel |
Material cylinder barrel | High-alloy stainless steel |
Manufacturer Nr. | DSNU-50-200-PPS-A |
---|---|
Manufacturer | Festo |
EAN | 4052568205980 |
Weight | 1.900000 |
HS-Code | 84123100 |
