€1,647.78
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-562775
Manufacturer Nr.
EGSK-33-400-6P
Electrical slide
Frequently Bought Together
-
This Item:
€1,647.78Excl. 19% VAT , excl. Shipping Cost
-
Festo 8048306. Mini slide EGSC-BS-KF-32-25-8P
€513.72Excl. 19% VAT , excl. Shipping Cost
-
Festo 8022568. electric drive ESBF-BS-32-400-10P
€1,106.87Excl. 19% VAT , excl. Shipping Cost
Total price
Working stroke | 400 mm |
Size | 33 |
Reversing backlash theoretical | 20 µm |
Spindle diameter | 10 mm |
Spindle pitch | 6 mm/U |
Mounting position | optional |
Guide | Recirculating ball bearing guide |
Design | Electromechanical linear axis With ball screw drive |
Referencing | Reference switch |
Spindle type | Ball screw drive |
Symbol | 00991211 |
Max. acceleration | 20 m/s² |
Max. speed | 0.47 m/s |
Repetition accuracy | ±0.01 mm |
Corrosion resistance class CRC | 0 - No corrosion stress |
LABS (PWIS) conformity | VDMA24364 zone III |
Degree of protection | IP10 |
Ambient temperature | 0 °C ... 40 °C |
Dynamic basic load rating fixed bearing | 1790 N |
Dynamic basic load rating linear guide | 9207 N |
Dynamic basic load rating ball screw | 2840 N |
2nd moment of area Iy | 62000 mm⁴ |
2nd moment of area Iz | 380000 mm⁴ |
Max. drive torque | 0.14 Nm |
Max. force Fy | 2469 N |
Max. force Fz | 2469 N |
Max. moment Mx | 50.1 Nm |
Max. moment My | 16.4 Nm |
Max. moment Mz | 16.4 Nm |
Max. feed force Fx | 150 N |
Frictional torque independent of load | 0.07 Nm |
Static basic load rating ball screw | 4900 N |
Static basic load rating linear guide | 20200 N |
Mass moment of inertia JH per metre of stroke | 0.0771 kgcm² |
Mass moment of inertia JO | 0.0115 kgcm² |
Feed constant | 6 mm/U |
Static basic load rating fixed bearing | 2590 N |
Reference value operational performance | 3000 km |
Moving mass | 310 g |
Weight of slide | 310 g |
Product weight | 3900 g |
Weight of additional slide | 310 g |
Basic weight for 0 mm stroke | 1380 g |
Additional weight per 10 mm stroke | 63 g |
Type of mounting | Via female thread and dowel pin |
Material end cap | Die-cast aluminium Coated |
Material profile | Coated High-alloy steel |
Note on materials | RoHS-compliant |
Material drive cover | Die-cast aluminium Coated |
Material slide | Steel |
Material spindle nut | Steel |
Material spindle | Steel |
Manufacturer Nr. | EGSK-33-400-6P |
---|---|
Manufacturer | Festo |
EAN | 4052568209834 |
Weight | 6.000000 |
HS-Code | 84799070 |
