Festo 562781. Electrical slide EGSK-33-400-10P
€1,647.78
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-562781
Manufacturer Nr.
EGSK-33-400-10P
Electrical slide
Frequently Bought Together
-
This Item:
€1,647.78Excl. 19% VAT , excl. Shipping Cost
-
Festo 8048300. Mini slide EGSC-BS-KF-45-25-10P
€595.52Excl. 19% VAT , excl. Shipping Cost
-
Festo 562758. Electrical slide EGSK-20-25-1P
€866.68Excl. 19% VAT , excl. Shipping Cost
Total price
| Working stroke | 400 mm |
| Size | 33 |
| Reversing backlash theoretical | 20 µm |
| Spindle diameter | 10 mm |
| Spindle pitch | 10 mm/U |
| Mounting position | optional |
| Guide | Recirculating ball bearing guide |
| Design | Electromechanical linear axis With ball screw drive |
| Referencing | Reference switch |
| Spindle type | Ball screw drive |
| Symbol | 00991211 |
| Max. acceleration | 20 m/s² |
| Max. speed | 0.79 m/s |
| Repetition accuracy | ±0.01 mm |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Degree of protection | IP10 |
| Ambient temperature | 0 °C ... 40 °C |
| Dynamic basic load rating fixed bearing | 1790 N |
| Dynamic basic load rating linear guide | 9207 N |
| Dynamic basic load rating ball screw | 1760 N |
| 2nd moment of area Iy | 62000 mm⁴ |
| 2nd moment of area Iz | 380000 mm⁴ |
| Max. drive torque | 0.24 Nm |
| Max. force Fy | 2083 N |
| Max. force Fz | 2083 N |
| Max. moment Mx | 42.2 Nm |
| Max. moment My | 13.8 Nm |
| Max. moment Mz | 13.8 Nm |
| Max. feed force Fx | 148 N |
| Frictional torque independent of load | 0.07 Nm |
| Static basic load rating ball screw | 2840 N |
| Static basic load rating linear guide | 20200 N |
| Mass moment of inertia JH per metre of stroke | 0.0771 kgcm² |
| Mass moment of inertia JO | 0.0166 kgcm² |
| Feed constant | 10 mm/U |
| Static basic load rating fixed bearing | 2590 N |
| Reference value operational performance | 5000 km |
| Moving mass | 310 g |
| Weight of slide | 310 g |
| Product weight | 3900 g |
| Weight of additional slide | 310 g |
| Basic weight for 0 mm stroke | 1380 g |
| Additional weight per 10 mm stroke | 63 g |
| Type of mounting | Via female thread and dowel pin |
| Material end cap | Die-cast aluminium Coated |
| Material profile | Coated High-alloy steel |
| Note on materials | RoHS-compliant |
| Material drive cover | Die-cast aluminium Coated |
| Material slide | Steel |
| Material spindle nut | Steel |
| Material spindle | Steel |
| Manufacturer Nr. | EGSK-33-400-10P |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568209896 |
| Weight | 5.000000 |
| HS-Code | 84799070 |
