Festo 538310. Proximity sensor SIEF-M8NB-NS-K-L
€78.98
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-538310
Manufacturer Nr.
SIEF-M8NB-NS-K-L
Proximity sensor
Frequently Bought Together
-
This Item:
€78.98Excl. 19% VAT , excl. Shipping Cost
-
Festo 150382. Proximity sensor SIEN-6,5B-PO-K-L
€66.13Excl. 19% VAT , excl. Shipping Cost
-
Festo 150454. Proximity sensor SIEH-M12B-PO-K-L
€66.13Excl. 19% VAT , excl. Shipping Cost
Total price
| Design | Round |
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991704 |
| Approval | RCM trademark c UL us listed (OL) |
| CE mark (see declaration of conformity) | To EU EMC Directive |
| Measuring principle | Inductive |
| Rated operating distance | 4 mm |
| Assured operating distance | 3.24 mm |
| Reduction factors | Aluminium = 1.0 Stainless steel St 18/8 = 1.0 Copper = 1.0 Brass = 1.0 Steel St 37 = 1.0 |
| Ambient temperature | -30 °C ... 85 °C |
| Repetition accuracy | 0.08 mm |
| Switching output | NPN |
| Switching element function | N/O contact |
| Hysteresis | 0.12 mm ... 0.6 mm |
| Max. switching frequency DC | 2000 Hz |
| Max. output current | 150 mA |
| Voltage drop | 1.8 V |
| Short circuit current rating | Pulsed |
| Operational voltage range DC | 10 V ... 30 V |
| Residual ripple | 10 % |
| No-load supply current | 15 mA |
| Reverse polarity protection | For all electrical connections |
| Electrical connection | 3-wire Cable |
| Cable length | 2.5 m |
| Material cable sheath | TPE-U(PUR) |
| Material insulating sheath | PVC |
| Size | M8 |
| Type of mounting | Via lock nut |
| Tightening torque | 10 Nm |
| Mounting type | Partially flush |
| Product weight | 77 g |
| Material housing | PA High-alloy stainless steel |
| Switching status indication | Yellow LED |
| Ambient temperature with moving cable | 0 °C ... 80 °C |
| Degree of protection | IP67 |
| Immunity to magnetic fields | Magnetic direct and alternating field |
| Corrosion resistance class CRC | 4 - Very high corrosion stress |
| Additional information for sensor selection | Reduction factor 1, resistant to magnetic fields |
| Electrical output | NPN |
| Selection of sensor design | Standard |
| Manufacturer Nr. | SIEF-M8NB-NS-K-L |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568089139 |
| Weight | 0.070000 |
| HS-Code | 85365019 |
