Festo 188108. Short-stroke cylinder ADVC-16-5-I-P-A

Name: Festo 188108. Short-stroke cylinder ADVC-16-5-I-P-A
Brand: Festo
SKU: FES-188108
Price: 55.66 EUR
Availability: InStock

€55.66

Excl. 19% VAT , excl. Shipping Cost

Article

FES-188108

Manufacturer Nr.

ADVC-16-5-I-P-A

Short-stroke cylinder

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 188108. Short-stroke cylinder ADVC-16-5-I-P-A
€55.66
Excl. 19% VAT , excl. Shipping Cost
Festo 188211. Short-stroke cylinder ADVC-32-15-I-P
€70.16
Excl. 19% VAT , excl. Shipping Cost
Festo 188247. Short-stroke cylinder ADVC-40-5-A-P
€87.56
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke	5 mm
Piston diameter	16 mm
Cushioning	Elastic cushioning rings/plates at both ends
Mounting position	optional
Mode of operation	Double-acting
Design	Piston Piston rod
Position detection	Via proximity switch
Symbol	00991217
Operating pressure	0.1 MPa ... 1 MPa
Operating pressure	1 bar ... 10 bar
Operating pressure	14.5 psi ... 145 psi
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20 °C ... 80 °C
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke	90 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke	121 N
Moving mass	15 g
Moving mass for 0 mm stroke	13 g
Additional moving mass per 10 mm stroke	4 g
Product weight	76 g
Basic weight for 0 mm stroke	69 g
Additional weight per 10 mm stroke	20 g
Type of mounting	Either: With through-hole With accessories
Pneumatic connection	M5
Note on materials	RoHS-compliant
Material cover	Wrought aluminium alloy Anodised
Material seals	TPE-U(PU)
Material housing	Wrought aluminium alloy Anodised
Material piston rod	High-alloy steel
