2/2-way ES solenoid valve G 1/4", 0 to 15 bar, open (NO) without power
-
This Item:
€187.66Excl. 19% VAT , excl. Shipping Cost
-
MO-220-ES-230V. 2/2-way ES solenoid valve G 2", 0,5 to 16 bar, open (NO) without power
€1,841.69Excl. 19% VAT , excl. Shipping Cost
-
M-214-ES-115V. 2/2-way ES solenoid valve G 1/4", 0 to 15 bar, closed (NC) without power
€146.01Excl. 19% VAT , excl. Shipping Cost
Materials:
Body G 1/8" and G 1/4": 1.4104, G 1/2" to G 2": 1.4581 (internal parts 1.4104), seal: FKM
Temperature range:
-20°C to +130°C, ambience: -10°C to +50°C
Media:
Compressed air, neutral gases, water, neutral low-viscosity media, other media on request
Installation position:
With upright magnets, (G 3/8" - G 2" also with horizontal magnets)
Control voltages:
Standard: 24 V DC, 230 V AC, upon request other voltages
Voltage tolerance:
± 10 %
Protection class:
IP 65 (plug size 3)
Information:
These valves are always supplied with a solenoid coil and a connector plug.
Warning:
For opening or closing, servo-controlled valves require a pressure difference between the valve inlet and valve outlet. The pressure difference is given as minimum pressure. There is a pressure compensation in the valve, resulting that no or little medium is used at the valve outlet, the valve will no longer function (it opens or closes unreliably).
Manufacturer Nr. | MO 214 ES 115V |
---|---|
Manufacturer | Fluidics equipment |
EAN | 4050571494285 |
Weight | 0.100000 |
HS-Code | 84818099 |
