Festo 8001460. Check valve VBNF-LBA-G18-Q6
Manufacturer Nr.
VBNF-LBA-G18-Q6
Frequently Bought Together
Valve function Piloted non-return function Selection of additional functions Manually exhausted Pneumatic connection, port 1 QS-6 Pneumatic connection, port 2 G1/8 Pilot air port 21 QS-6 Type of mounting Screw-in Operating pressure 0.2 bar ... 10 bar Pilot pressure 2 bar ... 10 bar Ambient temperature -10 °C ... 60 °C Material housing PBT Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Mounting position optional Type act., cont. n.-r. func. Pneumatic Manual exhaust function Non-detenting Symbol 00991957 Rotatability 360°/no continuous swivelling permissible Operating pressure complete temperature range 0.2 bar ... 10 bar Standard flow rate 1->2 (6-0) 500 l/min Standard nominal flow rate 1->2 (6-5) 260 l/min Switching time off 9 ms Switching time on 6 ms Explosion protection Zone 2 (ATEX)
Zone 22 (ATEX) Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature -10 °C ... 60 °C Pilot medium Compressed air to ISO 8573-1:2010 [7:4:4] Nominal torque 6 Nm Tolerance for nominal tightening torque ± 20% Product weight 27.3 g Material covering ES-BE Note on materials RoHS-compliant Material cover PBT Material seals NBR Material hollow bolt Wrought aluminium alloy Material release ring POM
More Information
Manufacturer Nr.
VBNF-LBA-G18-Q6
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568109578
Weight
0.029000
HS-Code
84813099
Article authenticity
Original product
Condition of article
New
