Festo 153477. Shut-off valve HE-3-QS-10
Manufacturer Nr.
HE-3-QS-10
Frequently Bought Together
Valve function 3/2 double solenoid Selection of additional functions With exhaust function Pneumatic connection, port 1 QS-10 Pneumatic connection, port 2 QS-10 Type of actuation Manual Type of mounting Either:
Direct mounting via through-hole
In-line installation Standard nominal flow rate 752.4 l/min Nominal size 4.6 mm Operating pressure -0.095 MPa ... 1 MPa Operating pressure -0.95 bar ... 10 bar Ambient temperature 0 °C ... 60 °C Material housing PBT-reinforced Operating medium Compressed air to ISO 8573-1:2010 [7:-:-] Exhaust-air function Without flow control option Sealing principle Soft Mounting position optional Design Piston gate valve Type of piloting Direct Flow direction Non-reversible Symbol 00997329 Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Cleanroom class Class 4 according to ISO 14644-1 Media temperature 0 °C ... 60 °C Product weight 41 g Pneumatic connection, port 3 Not ducted Note on materials RoHS-compliant Material seals NBR
More Information
Manufacturer Nr.
HE-3-QS-10
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568034931
Weight
0.042000
HS-Code
84812090
Article authenticity
Original product
Condition of article
New
