Festo 530041. Piloted check valve HGL-1/4-QS-8
Manufacturer Nr.
HGL-1/4-QS-8
Frequently Bought Together
Valve function Piloted non-return function Pneumatic connection, port 1 QS-8 Pneumatic connection, port 2 G1/4 Pilot air port 21 G1/8 Type of actuation Pneumatic Type of mounting Screw-in
Via male thread Operating pressure 0.05 MPa ... 1 MPa Operating pressure 0.5 bar ... 10 bar Pilot pressure 0.2 MPa ... 1 MPa Pilot pressure 2 bar ... 10 bar Pilot pressure 29 psi ... 145 psi Ambient temperature -10 °C ... 60 °C Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Maritime classification See certificate Mounting position optional Symbol 00991456 Standard flow rate 1->2 (6-0) 640 l/min Standard nominal flow rate 1->2 (6-5) 390 l/min Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Cleanroom class Class 4 according to ISO 14644-1 Storage temperature -10 °C ... 60 °C Media temperature -10 °C ... 60 °C Pilot medium Compressed air to ISO 8573-1:2010 [7:4:4] Nominal torque 11 Nm Tolerance for nominal tightening torque ± 10% Product weight 38.7 g Note on materials RoHS-compliant Material seals NBR Material hollow bolt Wrought aluminium alloy
Anodised Material release ring POM Material non-return collar NBR Material swivel fitting Die-cast zinc
More Information
Manufacturer Nr.
HGL-1/4-QS-8
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568015787
Weight
0.040000
HS-Code
84813099
Article authenticity
Original product
Condition of article
New
