Festo 152618. Pressure switch PEV-W-KL-LED-GH
Manufacturer Nr.
PEV-W-KL-LED-GH
Frequently Bought Together
Symbol 00991472 Approval RCM trademark CE mark (see declaration of conformity) To EU EMC Directive
In accordance with EU RoHS Directive CE marking (see declaration of conformity) To UK instructions for EMC
To UK RoHS instructions Note on materials RoHS-compliant Measured variable Relative pressure Measurement method Pneumatic/electric pressure transducer Pressure measuring range 2 bar ... 8 bar Operating pressure 0 bar ... 8 bar Max. overload pressure 20 bar Operating medium Compressed air to ISO 8573-1:2010 [7:-:-] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Media temperature 0 °C ... 60 °C Ambient temperature 0 °C ... 60 °C Switching element function Changeover switch Hysteresis 0.5 bar ... 2 bar Max. switching frequency 3 Hz Max. output current 2500 mA Operational voltage range DC 10 V ... 30 V Electrical connection 4-pin
Screw terminal Type of mounting Either:
With through-hole
With H-rail Mounting position optional Pneumatic connection M5 Product weight 56 g Material housing PA
PET
POM Material membrane NBR Switching status indication Yellow LED Setting range threshold value 2 bar ... 8 bar Degree of protection IP20 Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364 zone III
More Information
Manufacturer Nr.
PEV-W-KL-LED-GH
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568010898
Weight
0.090000
HS-Code
85365019
Article authenticity
Original product
Condition of article
New
