Festo 11689. Check valve H-1/4-B

Name: Festo 11689. Check valve H-1/4-B
Brand: Festo
SKU: FES-11689
Price: 32.89 EUR
Availability: InStock

€32.89

Excl. 19% VAT , excl. Shipping Cost

Article

FES-11689

Manufacturer Nr.

H-1/4-B

Check valve

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 11689. Check valve H-1/4-B
€32.89
Excl. 19% VAT , excl. Shipping Cost
Festo 548002. Quick exhaust valve VBQF-U-G14-Q8
€49.81
Excl. 19% VAT , excl. Shipping Cost
Festo 153470. Shut-off valve HE-2-QS-12
€20.24
Excl. 19% VAT , excl. Shipping Cost

Total price

Valve function	Non-return function
Pneumatic connection, port 1	G1/4
Pneumatic connection, port 2	G1/4
Type of mounting	Screw-in
Operating pressure	0.04 MPa ... 1.2 MPa
Operating pressure	0.4 bar ... 12 bar
Ambient temperature	-10 °C ... 60 °C
Material housing	Wrought aluminium alloy Anodised
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Mounting position	optional
Symbol	00991455
Standard nominal flow rate 1->2 (6-5)	1000 l/min
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B2-L
Media temperature	-10 °C ... 60 °C
Pilot medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Max. tightening torque	11 Nm
Product weight	25.4 g
Note on materials	RoHS-compliant
Material seals	NBR

More Information
Manufacturer Nr.	H-1/4-B
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568002398
Weight	0.027000
HS-Code	84813099
Article authenticity	Original product
Condition of article	New
