Festo 4834295. Ball valve VZBE-2-T-63-F-3L-F0507-V15V15

Name: Festo 4834295. Ball valve VZBE-2-T-63-F-3L-F0507-V15V15
Brand: Festo
SKU: FES-4834295
Price: 495.55 EUR
Availability: InStock

€495.55

Excl. 19% VAT , excl. Shipping Cost

Article

FES-4834295

Manufacturer: Festo

Manufacturer Nr.

VZBE-2-T-63-F-3L-F0507-V15V15

Ball valve

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 4834295. Ball valve VZBE-2-T-63-F-3L-F0507-V15V15
€495.55
Excl. 19% VAT , excl. Shipping Cost
Festo 1002548. Angle seat valve VZXF-L-M22C-M-B-N34-180-M1-V4V4T-50-20
€230.37
Excl. 19% VAT , excl. Shipping Cost
Festo 3540146. Angle seat valve VZXF-L-M22C-M-B-G2-450-M1-V4B2T-50-3
€456.97
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Information

Downloads

Design	3-way ball valve L-hole
Type of actuation	Mechanical
Sealing principle	Soft
Mounting position	optional
Type of mounting	In-line installation
Connection Process valve	2 NPT
Switching position indicator	Slot direction = flow direction
Flange hole pattern	F0507
Inside diameter	38.1 mm
Nominal size DN	50
Valve function	3/2
Flow direction	Reversible
Nominal pressure PN	63
Breakaway torque at differential pressure, nominal pressure, process valve PN	85 Nm
Based on standard	ASME B1.20.1 ISO 5211
Symbol	00991888
Medium	Vapour Compressed air to ISO 8573-1:2010 [-:-:-] Inert gases Water Neutral fluids
Media temperature	-20 °C ... 200 °C
Flow rate Kv L hole	78 m³/h
Note on materials	RoHS-compliant
LABS (PWIS) conformity	VDMA24364 zone III
Material housing	Stainless steel casting
Material number housing	1.4408
Material seat seal	PTFE
Material seals	PTFE
Material ball	Stainless steel casting
Material number ball	1.4408
Material shaft	High-alloy stainless steel
Material number shaft	1.4401
Product weight	5560 g
Approval	CRN
CE mark (see declaration of conformity)	In accordance with EU Pressure Equipment Directive
Explosion protection	Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)
Corrosion resistance class CRC	4 - Very high corrosion stress

More Information
Manufacturer Nr.	VZBE-2-T-63-F-3L-F0507-V15V15
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568275761
Weight	0.100000
HS-Code	84818081
Article authenticity	Original product
Condition of article	New
