Festo 18779. Plug SEA-GS-11-DUO
Manufacturer Nr.
SEA-GS-11-DUO
Frequently Bought Together
Based on standard EN 61076-2-101
EN 61984 Type of mounting Via threaded sleeve Mounting position optional Product weight 24 g Electrical connection 4-pin
Type A
M12x1
Straight plug connector/screw terminal Operational voltage range DC 250 V Operational voltage range AC 250 V Current rating at 40° C 4 A Immunity to surge 2.5 kV Cable fitting Pg11 Permissible cable diameter 2 x 3 mm or 2 x 5 mm Connection cross section 0.75 mm² Degree of protection IP67 Ambient temperature -40 °C ... 85 °C CE mark (see declaration of conformity) To EU Low Voltage Directive CE marking (see declaration of conformity) To UK regulations for electrical equipment LABS (PWIS) conformity VDMA24364-B2-L Note on materials RoHS-compliant Pollution degree 3 Corrosion resistance class CRC 2 - Moderate corrosion stress Material housing PBT Housing colour Black Material union nut PBT Material electrical contact Brass
White bronze coated
More Information
Manufacturer Nr.
SEA-GS-11-DUO
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568022372
Weight
0.024000
HS-Code
85366990
Article authenticity
Original product
Condition of article
New
