Festo 1067905. Plug socket NECU-M-B12G5-C2-PB
Manufacturer Nr.
NECU-M-B12G5-C2-PB
Frequently Bought Together
Based on standard EN 61076-2-101
EN 61984 Product weight 48.7 g Electrical connection 1 Straight socket, M12x1, 5-pin, B-coded, screenable Plug encoding B Electrical connection 2 Screw terminal, can be screened Operational voltage range DC 0 V ... 125 V Operational voltage range AC 0 V ... 125 V Current rating at 40° C 4 A Immunity to surge 1.5 kV Transmission characteristics DIN EN 50173/CAT 5 Permissible cable diameter 6 mm ... 8 mm Connection cross section 0.14 mm² ... 0.75 mm² Degree of protection IP67 Ambient temperature -25 °C ... 85 °C CE mark (see declaration of conformity) To EU Low Voltage Directive LABS (PWIS) conformity VDMA24364-B2-L Note on materials RoHS-compliant Pollution degree 3 Corrosion resistance class CRC 1 - Low corrosion stress Material housing Die-cast zinc
Nickel-plated Material electrical contact Brass
Bronze
More Information
Manufacturer Nr.
NECU-M-B12G5-C2-PB
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568104856
Weight
0.049000
HS-Code
85366990
Article authenticity
Original product
Condition of article
New
