Festo 151687. Plug socket MSSD-EB
Frequently Bought Together
Type of mounting On solenoid valve via M2.5 central screw Cable outlet Angled Note on cable outlet 90° rotatable Mounting position optional Product weight 11 g Electrical connection 3-pin
Socket
Angled socket
Type C
To DIN EN 175301-803
To DIN EN 61984
Square design MSEB
Square design MSN2 Electrical connection 1, design Angular Electrical connection 1, connection type Socket Electrical connection 1, cable outlet Angled Electrical connection 1, number of connections/cores 3 Electrical connection 1, connection pattern 00995650 Electrical connection 2 Screw terminal Operational voltage range DC 0 V ... 300 V Operational voltage range AC 0 V ... 250 V Current rating at 40° C 6 A Permissible current load 6 A Immunity to surge 4 kV Protective conductor connection Available Cable fitting Pg7 Cable diameter 6 mm ... 8 mm Permissible cable diameter 7.5 mm Nominal cross section conductor 0.75 mm² Connection cross section 0.75 mm² Degree of protection IP65
To IEC 60529 Note on degree of protection In assembled state Ambient temperature -45 °C ... 90 °C CE mark (see declaration of conformity) To EU Low Voltage Directive
In accordance with EU RoHS Directive CE marking (see declaration of conformity) To UK regulations for electrical equipment
To UK RoHS instructions LABS (PWIS) conformity VDMA24364-B2-L Pollution degree 3 Material housing Polymer Housing colour Black Material seals NBR
More Information
Manufacturer Nr.
MSSD-EB
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568010720
Weight
0.017000
HS-Code
85366990
Article authenticity
Original product
Condition of article
New
