Festo 525659. Parallel gripper HGPP-10-A-G1
Manufacturer Nr.
HGPP-10-A-G1
Frequently Bought Together
Size 10 Stroke per gripper jaws 2 mm Max. replacement accuracy 0.1 mm Repetition accuracy, gripper 0.02 mm Number of gripper jaws 2 Drive system Pneumatic Mode of operation Double-acting Gripper function Parallel Gripper force back-up During opening Design Rack and pinion Position detection Via Hall sensor
Via inductive sensors Symbol 00995947 Operating pressure 5 bar ... 8 bar Max. operating frequency of gripper 4 Hz Min. opening time at 0.6 MPa (6 bar, 87 psi) 24 ms Min. closing time at 0.6 MPa (6 bar, 87 psi) 95 ms Max. mass per external gripper finger 50 g Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Ambient temperature 5 °C ... 60 °C Max. force on gripper jaw Fz static 40 N Max. torque at gripper Mx static 1.5 Nm Max. torque at gripper My static 1.5 Nm Max. torque at gripper Mz static 1.5 Nm Product weight 127 g Type of mounting Via female thread Pneumatic connection M3 Note on materials RoHS-compliant Material cover cap POM Material housing Hard anodised wrought aluminium alloy Material gripper jaws Wrought aluminium alloy, nickel-plated
More Information
Manufacturer Nr.
HGPP-10-A-G1
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568161828
Weight
0.280000
HS-Code
84798997
Article authenticity
Original product
Condition of article
New
