Festo 3361483. Parallel gripper HGPL-25-20-A-B
Manufacturer Nr.
HGPL-25-20-A-B
Frequently Bought Together
Size 25 Stroke per gripper jaws 20 mm Max. replacement accuracy 0.2 mm Max. angular gripper jaw backlash ax, ay 0.2 deg Max. gripper jaw backlash Sz 0.05 mm Rotationally symmetrical 0.2 mm Repetition accuracy, gripper 0.03 mm Number of gripper jaws 2 Drive system Pneumatic Mounting position optional Mode of operation Double-acting Gripper function Parallel Gripper force back-up None Design Twin piston
Guidance
Piston gate valve
T-shape
Rack and pinion Position detection Via proximity switch Symbol 00991894 Gripping force per gripper jaw, opening, 0.6 MPa (6 bar, 87 psi) 412 N Gripping force per gripper jaw, closing, 0.6 MPa (6 bar, 87 psi) 512 N Operating pressure 3 bar ... 8 bar Max. operating frequency of gripper 1 Hz Min. opening time at 0.6 MPa (6 bar, 87 psi) 170 ms Min. closing time at 0.6 MPa (6 bar, 87 psi) 150 ms Max. mass per external gripper finger 250 g Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature 5 °C ... 60 °C Gripper force per gripper jaw, opening, 0.6 MPa (6 bar, 87 psi) 206 N Gripper force per gripper jaw, closing, 0.6 MPa (6 bar, 87 psi) 256 N Mass moment of inertia 11.98 kgcm² Max. force on gripper jaw Fz static 1500 N Max. torque at gripper Mx static 100 Nm Max. torque at gripper My static 60 Nm Max. torque at gripper Mz static 70 Nm Lubrication interval for guide components 5 MioCyc Product weight 1015 g Type of mounting Via female thread and centring sleeve
Via through-hole and centring sleeve Pneumatic connection M5 Note on materials RoHS-compliant Material housing Smooth-anodised wrought aluminium alloy Material gripper jaws Hardened steel
More Information
Manufacturer Nr.
HGPL-25-20-A-B
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568269203
Weight
1.000000
HS-Code
84798997
Article authenticity
Original product
Condition of article
New
