Festo 526007. Suction cup without connector ESV-50-BT
Manufacturer Nr.
ESV-50-BT
Suction cup without connector
Frequently Bought Together
Height compensator for suction-cup holder 10 mm Min. workpiece radius 40 mm Suction cup diameter 50 mm Suction cup volume 17.6 cm³ Mounting position optional Design Bellows Symbol 00991485 Suction cup shape Round bellows 1.5 convolutions Operating pressure -0.95 bar ... 0 bar Nominal operating pressure -0.7 bar Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-] LABS (PWIS) conformity VDMA24364-A1-L Ambient temperature -10 °C ... 80 °C Breakaway force at 70% vacuum 100 N Holding force at nominal operating pressure 100 N Lateral force at nominal operating pressure 39 N Product weight 16.2 g Type of mounting Via vacuum port Colour Red-brown Shore hardness 72 +/- 5 Note on materials RoHS-compliant Material suction cup Vulkollan
More Information
Manufacturer Nr.
ESV-50-BT
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568083335
Weight
0.020000
HS-Code
84799070
Article authenticity
Original product
Condition of article
New
