Festo 189375. Suction cup complete ESS-10-BU
Manufacturer Nr.
ESS-10-BU
Frequently Bought Together
Height compensator for suction cup 4 mm Min. workpiece radius 20 mm Nominal size 2 mm Suction cup diameter 10 mm Suction cup volume 0.38 cm³ Position of connection Top Mounting position optional Symbol 00991485 Correlation to suction-cup holder Size 3 Suction cup shape Round bellows 1.5 convolutions Operating pressure -0.095 MPa ... 0 MPa Operating pressure -0.95 bar ... 0 bar Operating pressure -13.775 psi ... 0 psi Nominal operating pressure -0.07 MPa Nominal operating pressure -0.7 bar Nominal operating pressure -10.15 psi Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-] Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364 zone III Suitable for use with food See supplementary material information Ambient temperature -20 °C ... 60 °C Holding force at nominal operating pressure 4.7 N Lateral force at nominal operating pressure 3 N Product weight 1.8 g Type of mounting Via vacuum port Vacuum connection M4 Colour Blue Shore hardness 60 +/- 5 Material screwed plug Nickel-plated brass Note on materials RoHS-compliant Material suction cup PUR
More Information
Manufacturer Nr.
ESS-10-BU
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568042462
Weight
0.002600
HS-Code
84799070
Article authenticity
Original product
Condition of article
New
