Festo 189313. Suction cup complete ESS-50-SNA
Manufacturer Nr.
ESS-50-SNA
Frequently Bought Together
Min. workpiece radius 330 mm Nominal size 3 mm Suction cup diameter 50 mm Suction cup volume 2.387 cm³ Position of connection Top Mounting position optional Special characteristics Antistatic Symbol 00991485 Correlation to suction-cup holder Size 4 Suction cup shape Round, flat Operating pressure -0.095 MPa ... 0 MPa Operating pressure -0.95 bar ... 0 bar Operating pressure -13.775 psi ... 0 psi Nominal operating pressure -0.07 MPa Nominal operating pressure -0.7 bar Nominal operating pressure -10.15 psi Surface resistance 0 MOhm Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-] Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-A1-L Suitable for use with food See supplementary material information Ambient temperature -10 °C ... 70 °C Holding force at nominal operating pressure 105.8 N Lateral force at nominal operating pressure 81.5 N Product weight 22 g Type of mounting Via vacuum port Vacuum connection M6 Colour Black/white dot Shore hardness 50 +/- 5 Material screwed plug Nickel-plated wrought aluminium alloy
Nickel-plated brass
Steel, galvanised and chrome-plated Note on materials RoHS-compliant Material suction cup BR
More Information
Manufacturer Nr.
ESS-50-SNA
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568042257
Weight
0.022000
HS-Code
84799070
Article authenticity
Original product
Condition of article
New
