Festo 534305. Ball valve VAPB-3/4-F-40-F03

Name: Festo 534305. Ball valve VAPB-3/4-F-40-F03
Brand: Festo
SKU: FES-534305
Price: 25.51 EUR
Availability: InStock

€25.51

Excl. 19% VAT , excl. Shipping Cost

Article

FES-534305

Manufacturer Nr.

VAPB-3/4-F-40-F03

Ball valve

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

Total price

Design	2-way ball valve
Type of actuation	Mechanical
Sealing principle	Soft
Mounting position	optional
Type of mounting	In-line installation
Connection Process valve	Rp3/4
Switching position indicator	Slot direction = flow direction
Flange hole pattern	F03
Nominal size DN	20
Flow direction	Reversible
Nominal pressure PN	40
Breakaway torque at differential pressure, nominal pressure, process valve PN	6 Nm
Break-away torque at a differential pressure of 1 MPa (10 bar, 145 psi)	5.1 Nm
Based on standard	ISO 5211
Symbol	00991458
Medium	Compressed air to ISO 8573-1:2010 [-:-:-] Inert gases Water Neutral fluids
Media temperature	-20 °C ... 150 °C
Flow rate Kv	41 m³/h
Note on materials	RoHS-compliant
LABS (PWIS) conformity	VDMA24364 zone III
Material housing	Brass Nickel-plated
Material number housing	2.0402 CW617N
Material seals	HNBR PTFE
Material ball	Brass Hard-chrome-plated
Material number ball	2.0402 CW617N
Material shaft	Brass
Material number shaft	2.0401 CW614N
Product weight	500 g
Corrosion resistance class CRC	1 - Low corrosion stress

More Information
Manufacturer Nr.	VAPB-3/4-F-40-F03
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568048860
Weight	0.440000
HS-Code	84818081
Article authenticity	Original product
Condition of article	New
