Festo 30457. Proximity sensor SMEO-1-B
€96.71
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-30457
Manufacturer Nr.
SMEO-1-B
Proximity sensor
Frequently Bought Together
-
This Item:
€96.71Excl. 19% VAT , excl. Shipping Cost
-
Festo 551368. Proximity sensor SME-10M-DS-24V-E-0,3-Q-M8D
€35.58Excl. 19% VAT , excl. Shipping Cost
-
Festo 150855. Proximity sensor SME-8-K-LED-24
€40.97Excl. 19% VAT , excl. Shipping Cost
Total price
| Design | Block design |
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991624 |
| CE mark (see declaration of conformity) | To EU EMC Directive To EU Low Voltage Directive In accordance with EU RoHS Directive |
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK regulations for electrical equipment To UK RoHS instructions |
| Note on materials | RoHS-compliant |
| Measured variable | Position |
| Measuring principle | Magnetic reed |
| Ambient temperature | -20 °C ... 70 °C |
| Repetition accuracy | 0.2 mm |
| Switching output | Contacting, bipolar |
| Switching element function | N/O contact |
| Switch-on time | 0.5 ms |
| Switch-off time | 0.03 ms |
| Max. switching frequency | 500 Hz |
| Max. output current | 1000 mA |
| Max. output current AC | 1000 mA |
| Max. output current DC | 1000 mA |
| Max. switching capacity AC | 40 VA |
| Max. switching capacity DC | 40 W |
| Voltage drop | 0 V |
| Off-state current | 0 mA |
| Short circuit current rating | no |
| Overload protection | Not available |
| Operational voltage range AC | 0 V ... 250 V |
| Operational voltage range DC | 0 V ... 200 V |
| Reverse polarity protection | no |
| Electrical connection 1, connection type | Cable |
| Electrical connection 1, connector system | Open end |
| Electrical connection 1, number of connections/cores | 2 |
| Connection outlet orientation | In-line |
| Cable length | 2.5 m |
| Cable sheath colour | grey |
| Material cable sheath | PVC |
| Type of mounting | With accessories |
| Tightening torque | 2.9 Nm |
| Mounting position | optional |
| Product weight | 100 g |
| Housing colour | Black |
| Material housing | Epoxy resin PC PET Steel TPE-O Die-cast zinc |
| Ambient temperature with moving cable | -5 °C ... 70 °C |
| Degree of protection | IP67 |
| Insulation voltage | 250 V |
| Immunity to surge | 4 kV |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Pollution degree | 3 |
| Manufacturer Nr. | SMEO-1-B |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568003685 |
| Weight | 0.090000 |
| HS-Code | 85365080 |
| Article authenticity | Original product |
| Condition of article | New |
