Aventics Series MS01 3354418740 MS01-02-3/2CC-SR-D6X1-PA-GF

Name: Aventics Series MS01 3354418740 MS01-02-3/2CC-SR-D6X1-PA-GF
Brand: Aventics
SKU: AVE-3354418740
Price: 1328.86 EUR
Availability: InStock

€1,328.86

Excl. 19% VAT , excl. Shipping Cost

Article

AVE-3354418740

Manufacturer Nr.

3354418740

MS01-02-3/2CC-SR-D6X1-PA-GF

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Aventics Series MS01 3354418740 MS01-02-3/2CC-SR-D6X1-PA-GF
€1,328.86
Excl. 19% VAT , excl. Shipping Cost
Aventics Pressure sensor, Series PE6 R412007885 PE6-P2-L HYST. EINST
€98.44
Excl. 19% VAT , excl. Shipping Cost
Aventics Sensor mounting 1827020144 CB1-RND-050-050-SN1-SN2
€11.75
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Information

Downloads

Version	2x
Version	MS01-PA test block, variant I, with 2 x 3/2-directional valve
Standards	ISO 15407-1
Standards	26 mm
Length	115 mm
Grid dimension	27 mm
Cleaning pressure option	cleaning pressure can be connected
Compressed air connection standard	according to ISO 228-1
Compressed air connection input	G 1/4
Compressed air connection, exhaust	G 1/8
Compressed air connection output	Ø 6x1
Compressed air connection pilot air exhaust	G 1/8
Working pressure min.	4 bar
Working pressure max	10 bar
Min. ambient temperature	0 °C
Max. ambient temperature	50 °C
Min. medium temperature	0 °C
Max. medium temperature	50 °C
Medium	Compressed air
Max. particle size	5 µm
Oil content of compressed air min.	0 mg/m³
Oil content of compressed air max.	0.1 mg/m³
Protection class	IP65
Duty cycle	100 %
DC operating voltage	24 V

Test block MS01
Operating pressure 4 bar ... 10 bar

More Information
Manufacturer Nr.	3354418740
Manufacturer	Aventics
GPSR manufacturer information	AVENTICS GmbH, Ulmer Straße 4, DE-30880 Laatzen, aventics.com
Weight	2.500000
HS-Code	73269098
Article authenticity	Original product
Condition of article	New
