3/2-way vacuum valve, G 1", -0,9 to 1bar, 24 V DC
€2,469.57
Excl. 19% VAT ,
excl. Shipping Cost
Article
FL-067767
Manufacturer Nr.
M 310 VU H 24V=
3/2-way vacuum valve, G 1", -0,9 to 1bar, 24 V DC
Frequently Bought Together
-
This Item:
€2,469.57Excl. 19% VAT , excl. Shipping Cost
-
Flat suction cups, support rib, P,series- Ø 42x2mm, Silicone (50A), transparent
€10.96Excl. 19% VAT , excl. Shipping Cost
-
Bellows suction pad, 2,5-way, Ø 30x13mm, NBR (55A), black
€6.62Excl. 19% VAT , excl. Shipping Cost
Total price
Materials:
Body: brass, internal parts: 1.4104, seal: FKM
Temperature range:
-10 to +80 °C, environment: max. +35 °C
Media:
neutral, gaseous and liquid media, vacuum (max. -0.9 bar)
Installation position:
with upright magnets (type standard: any)
Control voltages:
24 V DC, 230 V AC
Voltage tolerance:
± 10 %
Protection class:
IP 65 (plug size 3)
Pressure input:
P (type Universal: possible at every connection)
Vacuum inlet:
P (type Universal: possible at every connection)
Note:
In a standard type, the breathing takes place via the anchor (M 5 female thread).
Information:
These valves are always supplied with a solenoid coil and a connector plug.
Body: brass, internal parts: 1.4104, seal: FKM
Temperature range:
-10 to +80 °C, environment: max. +35 °C
Media:
neutral, gaseous and liquid media, vacuum (max. -0.9 bar)
Installation position:
with upright magnets (type standard: any)
Control voltages:
24 V DC, 230 V AC
Voltage tolerance:
± 10 %
Protection class:
IP 65 (plug size 3)
Pressure input:
P (type Universal: possible at every connection)
Vacuum inlet:
P (type Universal: possible at every connection)
Note:
In a standard type, the breathing takes place via the anchor (M 5 female thread).
Information:
These valves are always supplied with a solenoid coil and a connector plug.
| Version | universal |
| Control voltage | 24 V DC |
| function | normally closed / open (NC / NO) |
| Thread (2x) | G 1" |
| Operating pressure [bar] | -0.9 to 1 |
| DN [mm] | 21 |
| Suction performance [m³/h] | 130 |
| Suction performance [l/min] | 2167 |
| Kv value* [l/min] | 88,3 |
| L [mm] | 96 |
| Power consumption (DC) [W] | 30 |
| Structural shape solenoid coil | F |
| Spare solenoid coil | MAG F 24V= |
| Manufacturer Nr. | M 310 VU H 24V= |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571477844 |
| Weight | 5.000000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
