3/2-way vacuum valve, G 3/4", -0,9 to 1bar, 230 V AC
€2,513.16
Excl. 19% VAT ,
excl. Shipping Cost
Article
FL-067770
Manufacturer Nr.
M 334 VU H 230V
3/2-way vacuum valve, G 3/4", -0,9 to 1bar, 230 V AC
Frequently Bought Together
-
This Item:
€2,513.16Excl. 19% VAT , excl. Shipping Cost
-
Multi stage ejectors to 70% vacuum, G 2", to 6400 l/min
€3,962.28Excl. 19% VAT , excl. Shipping Cost
-
Bellows suction pad, 4,5-way, P-series, Ø 41x20mm, CR (50A), black
€14.34Excl. 19% VAT , excl. Shipping Cost
Total price
Materials:
Body: brass, internal parts: 1.4104, seal: FKM
Temperature range:
-10 to +80 °C, environment: max. +35 °C
Media:
neutral, gaseous and liquid media, vacuum (max. -0.9 bar)
Installation position:
with upright magnets (type standard: any)
Control voltages:
24 V DC, 230 V AC
Voltage tolerance:
± 10 %
Protection class:
IP 65 (plug size 3)
Pressure input:
P (type Universal: possible at every connection)
Vacuum inlet:
P (type Universal: possible at every connection)
Note:
In a standard type, the breathing takes place via the anchor (M 5 female thread).
Information:
These valves are always supplied with a solenoid coil and a connector plug.
Body: brass, internal parts: 1.4104, seal: FKM
Temperature range:
-10 to +80 °C, environment: max. +35 °C
Media:
neutral, gaseous and liquid media, vacuum (max. -0.9 bar)
Installation position:
with upright magnets (type standard: any)
Control voltages:
24 V DC, 230 V AC
Voltage tolerance:
± 10 %
Protection class:
IP 65 (plug size 3)
Pressure input:
P (type Universal: possible at every connection)
Vacuum inlet:
P (type Universal: possible at every connection)
Note:
In a standard type, the breathing takes place via the anchor (M 5 female thread).
Information:
These valves are always supplied with a solenoid coil and a connector plug.
| Version | universal |
| Control voltage | 230 V AC |
| function | normally closed / open (NC / NO) |
| Thread (2x) | G 3/4" |
| Operating pressure [bar] | -0.9 to 1 |
| DN [mm] | 21 |
| Suction performance [m³/h] | 130 |
| Suction performance [l/min] | 2167 |
| Kv value* [l/min] | 88,3 |
| L [mm] | 96 |
| Power consumption (AC) [VA] | 34 |
| Structural shape solenoid coil | F |
| Spare solenoid coil | MAG F 230V |
| Manufacturer Nr. | M 334 VU H 230V |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571478520 |
| Weight | 6.000000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
