Festo 4795666. Ball valve VZBD-1/2-S1-16-T-2-F0304-V14V14
€100.44
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-4795666
Manufacturer Nr.
VZBD-1/2-S1-16-T-2-F0304-V14V#
Ball valve
Frequently Bought Together
-
This Item:
€100.44Excl. 19% VAT , excl. Shipping Cost
-
Festo 8060532. Angle seat valve VZXA-B-TS6-25-M2-V13T-30-M-90-26-V4
€624.57Excl. 19% VAT , excl. Shipping Cost
-
Festo 8060539. Angle seat valve VZXA-B-TS6-50-M2-V13T-10-M-90-26-V4
€867.26Excl. 19% VAT , excl. Shipping Cost
Total price
| Design | 2-way ball valve |
| Type of actuation | Mechanical |
| Sealing principle | Soft |
| Mounting position | optional |
| Type of mounting | In-line installation |
| Connection Process valve | Clamp to ASME-BPE |
| Switching position indicator | Slot direction = flow direction |
| Flange hole pattern | F0304 |
| Inside diameter | 9.6 mm |
| Nominal size DN | 15 |
| Valve function | 2/2 |
| Flow direction | Reversible |
| Nominal pressure PN | 16 |
| Breakaway torque at differential pressure, nominal pressure, process valve PN | 7 Nm |
| Based on standard | ASME BPE ISO 5211 |
| Symbol | 00991458 |
| Medium | Vapour Compressed air to ISO 8573-1:2010 [-:-:-] Inert gases Water Neutral fluids |
| Media temperature | -20 °C ... 200 °C |
| Flow rate Kv | 13 m³/h |
| Note on materials | RoHS-compliant |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Suitable for use with food | See supplementary material information |
| Material housing | Stainless steel casting |
| Material number housing | 1.4409 |
| Material seat seal | PTFE, modified |
| Material seals | FPM PTFE |
| Material ball | Stainless steel casting |
| Material number ball | 1.4409 |
| Material shaft | High-alloy stainless steel |
| Material number shaft | 1.4401 |
| Product weight | 430 g |
| Approval | 3-A sanitary CRN |
| Explosion protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
| Corrosion resistance class CRC | 4 - Very high corrosion stress |
| Manufacturer Nr. | VZBD-1/2-S1-16-T-2-F0304-V14V# |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568275334 |
| Weight | 0.100000 |
| HS-Code | 84818081 |
| Article authenticity | Original product |
| Condition of article | New |
