Festo 8034557. Sub-base VMPAL-AP-14-RV
€19.91
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-8034557
Manufacturer Nr.
VMPAL-AP-14-RV
Sub-base
Frequently Bought Together
-
This Item:
€19.91Excl. 19% VAT , excl. Shipping Cost
-
Festo 559638. Cover plate VMPA-P-RP
€88.20Excl. 19% VAT , excl. Shipping Cost
-
Festo VMPA2-AP-2-1-EMS-4 (546803) Sub-Base
€100.65Excl. 19% VAT , excl. Shipping Cost
Total price
| Construction width | 14 mm |
| Width | 14.9 mm |
| Length | 107.3 mm |
| Grid dimension | 14.9 mm |
| Integrated function | Check valve |
| Max. number of valve positions | 1 |
| Flow direction | Non-reversible |
| Valve terminal structure | Valve sizes can be mixed |
| Operating pressure | -0.09 MPa ... 1 MPa |
| Operating pressure | -0.9 bar ... 10 bar |
| Pilot pressure | 0.3 MPa ... 0.8 MPa |
| Pilot pressure | 3 bar ... 8 bar |
| Suitability for vacuum | no |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -5 °C ... 50 °C |
| Product weight | 35 g |
| Pneumatic connection, port 2 | For 14 mm cartridge |
| Pneumatic connection, port 4 | For 14 mm cartridge |
| Note on materials | RoHS-compliant |
| Material sub-base | PA-reinforced |
| Manufacturer Nr. | VMPAL-AP-14-RV |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568283629 |
| Weight | 0.060000 |
| HS-Code | 84819000 |
| Article authenticity | Original product |
| Condition of article | New |
