Festo 575998. Solenoid valve VUVB-ST12-M32C-MZH-QX-D-1T1
Manufacturer Nr.
VUVB-ST12-M32C-MZH-QX-D-1T1
Frequently Bought Together
Valve function 3/2-way, closed, monostable Type of actuation Electric Valve size 12 mm Standard nominal flow rate 240 l/min ... 400 l/min pneumatic working port QS-4
QS-6 Operating pressure 0.2 MPa ... 0.8 MPa Operating pressure 2 bar ... 8 bar Design Poppet valve with spring return Degree of protection IP65 Nominal size 4 mm Exhaust-air function Without flow control option Sealing principle Soft Mounting position optional Manual override Non-detenting Type of piloting Pilot actuated Pilot air supply External Flow direction Non-reversible Symbol 00992123 Note on operating pressure 0 - 0.8 MPa with ext. pilot air
0 - 8 bar with external pilot air Pilot pressure 0.2 MPa ... 0.8 MPa Pilot pressure 2 bar ... 8 bar Switching time off 14 ms Switching time on 6 ms Duty cycle 100% Max. positive test pulse with 0 signal 800 µs Max. negative test pulse with 1 signal 300 µs Characteristic coil data 24 V DC: 1.0 W Permissible voltage fluctuations +/- 10 % Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Vibration resistance Transport application test with severity level 1 to FN 942017-4 and EN 60068-2-6 Shock resistance Shock test with severity level 1 to FN 942017-5 and EN 60068-2-27 Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature -5 °C ... 60 °C Sound pressure level 85 dB(A) Ambient temperature -5 °C ... 60 °C Product weight 26.3 g Electrical connection Via sub-base Type of mounting On sub-base Auxiliary pilot air port 14 Sub-base Pneumatic connection, port 1 Sub-base Pneumatic connection, port 3 Sub-base Pneumatic connection, port 5 Sub-base Note on materials RoHS-compliant Material seals NBR
TPE-U(PU) Material housing PA-reinforced Material piston slide Wrought aluminium alloy
More Information
Manufacturer Nr.
VUVB-ST12-M32C-MZH-QX-D-1T1
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568104245
Weight
0.035000
HS-Code
84812090
Article authenticity
Original product
Condition of article
New
