Festo 1725842. Guide unit EAGF-V2-KF-63-100
Manufacturer Nr.
EAGF-V2-KF-63-100
Frequently Bought Together
Size 63 Stroke 100 mm Reversing backlash theoretical 0 µm Mounting position optional Guide Recirculating ball bearing guide Design Guidance Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Ambient temperature -20 °C ... 80 °C Max. force Fy 1260 N Max. force Fy static 1600 N Max. force Fz 1260 N Max. force Fz static 1600 N Max. moment Mx 75 Nm Max. torque Mx static 95 Nm Max. moment My 90 Nm Max. torque My static 115 Nm Max. moment Mz 90 Nm Max. torque Mz static 115 Nm Displacement force 15 N Moving mass 3045 g Product weight 6015 g Centre of gravity at 0 mm stroke 48 mm Centre of gravity additional of moving mass per 10 mm 4.1 mm Type of mounting Via female thread Note on materials RoHS-compliant Material guide component Tempered steel Material housing Wrought aluminium alloy
Anodised Material yoke plate Steel
More Information
Manufacturer Nr.
EAGF-V2-KF-63-100
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568246198
Weight
6.000000
HS-Code
84821090
Article authenticity
Original product
Condition of article
New
