Festo 554315. Sub-base VMPAL-AP-10-T135

Name: Festo 554315. Sub-base VMPAL-AP-10-T135
Brand: Festo
SKU: FES-554315
Price: 6.53 EUR
Availability: InStock

€6.53

Excl. 19% VAT , excl. Shipping Cost

Article

FES-554315

Manufacturer Nr.

VMPAL-AP-10-T135

Sub-base

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 554315. Sub-base VMPAL-AP-10-T135
€6.53
Excl. 19% VAT , excl. Shipping Cost
Festo 546805. Sub-base VMPA2-AP-2-1-EMM-4
€72.69
Excl. 19% VAT , excl. Shipping Cost
Festo 543339. Regulator plate VMPA1-B8-R1C2-C-10
€88.01
Excl. 19% VAT , excl. Shipping Cost

Total price

Width	10.7 mm
Length	107.3 mm
Grid dimension	10.7 mm
Valve size	10 mm
Pressure-zone division	Ducts 1, 3 and 5
Max. number of valve positions	1
Flow direction	Reversible
Valve terminal structure	Valve sizes can be mixed
Operating pressure	-0.09 MPa ... 1 MPa
Operating pressure	-0.9 bar ... 10 bar
Pilot pressure	0.3 MPa ... 0.8 MPa
Pilot pressure	3 bar ... 8 bar
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	3 - high corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-5 °C ... 50 °C
Product weight	25 g
Pneumatic connection, port 2	For 10 mm cartridge
Pneumatic connection, port 4	For 10 mm cartridge
Note on materials	RoHS-compliant
Material sub-base	PA-reinforced

More Information
Manufacturer Nr.	VMPAL-AP-10-T135
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568053659
Weight	0.049000
HS-Code	84819000
Article authenticity	Original product
Condition of article	New
