Festo 555757. Regulator plate VABF-S1-2-R1C2-C-6
€153.70
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-555757
Manufacturer Nr.
VABF-S1-2-R1C2-C-6
Regulator plate
Frequently Bought Together
-
This Item:
€153.70Excl. 19% VAT , excl. Shipping Cost
-
Festo 555765. Regulator plate VABF-S1-2-R5C2-C-6
€280.02Excl. 19% VAT , excl. Shipping Cost
-
Festo 546251. Regulator plate VABF-S4-1-R6C2-C-10
€152.35Excl. 19% VAT , excl. Shipping Cost
Total price
| Construction width | 54 mm |
| Based on standard | ISO 5599-1 |
| Mounting position | optional |
| Vertical pneumatic linkage | Pressure regulator for 1 |
| Controller function | Output pressure constant With secondary venting |
| Symbol | 00992227 |
| Selection of pressure gauge | Possible |
| Pressure regulation range | 0.05 MPa ... 0.6 MPa |
| Pressure regulation range | 0.5 bar ... 6 bar |
| Pressure regulation range | 7.25 psi ... 87 psi |
| Inlet pressure 1 | 0.5 bar ... 10 bar |
| Inlet pressure 1 | 0.05 MPa ... 1 MPa |
| Inlet pressure 1 | 7.25 psi ... 145 psi |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Degree of protection | IP65 NEMA 4 |
| Ambient temperature | -5 °C ... 50 °C |
| Product weight | 1190 g |
| Mounting with vertical stacking | On manifold sub-base On individual sub-base |
| Pressure gauge connection | Via retaining clamp |
| Note on materials | RoHS-compliant |
| Material control panel | PA |
| Material regulator housing | Die-cast aluminium |
| Manufacturer Nr. | VABF-S1-2-R1C2-C-6 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568199869 |
| Weight | 1.400000 |
| HS-Code | 84811099 |
| Article authenticity | Original product |
| Condition of article | New |
