Festo 540158. Regulator plate VABF-S4-1-R3C2-C-10
€145.83
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-540158
Manufacturer Nr.
VABF-S4-1-R3C2-C-10
Regulator plate
Frequently Bought Together
-
This Item:
€145.83Excl. 19% VAT , excl. Shipping Cost
-
Festo VABF-S1-1-R7C2-C-10 (546830) Regulator Plate
€162.84Excl. 19% VAT , excl. Shipping Cost
-
Festo VABF-S1-1-R6C2-C-6 (546827) Regulator Plate
€162.84Excl. 19% VAT , excl. Shipping Cost
Total price
| Construction width | 26 mm |
| Based on standard | ISO 15407-2 |
| Mounting position | optional |
| Controller function | Output pressure constant With secondary venting |
| Symbol | 00991579 |
| Selection of pressure gauge | Possible |
| Operating pressure | 1 MPa |
| Operating pressure | 10 bar |
| Pressure regulation range | 0.2 MPa ... 0.85 MPa |
| Pressure regulation range | 2 bar ... 8.5 bar |
| Pressure regulation range | 29 psi ... 123.25 psi |
| Inlet pressure 1 | 0.5 bar ... 10 bar |
| CE mark (see declaration of conformity) | To EU Low Voltage Directive |
| CE marking (see declaration of conformity) | To UK regulations for electrical equipment |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Degree of protection | IP65 NEMA 4 |
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -5 °C ... 50 °C |
| Product weight | 448 g |
| Mounting with vertical stacking | On manifold sub-base On individual sub-base |
| Pressure gauge connection | Via retaining clamp |
| Material control panel | PA |
| Material regulator housing | Die-cast aluminium |
| Manufacturer Nr. | VABF-S4-1-R3C2-C-10 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568178413 |
| Weight | 0.390000 |
| HS-Code | 84811099 |
| Article authenticity | Original product |
| Condition of article | New |
