Festo 570174. Mini slide DGSL-10-30-EA
Manufacturer Nr.
DGSL-10-30-EA
Frequently Bought Together
Stroke 30 mm Adjustable end position range/length front 13 mm Adjustable end position range/length rear 5.5 mm Piston diameter 12 mm Operating mode, drive unit Yoke Cushioning Short elastic cushioning rings/pads at both ends Mounting position optional Guide Ball bearing cage guide Design Yoke
Piston
Piston rod
Slide Position detection Via proximity switch Symbol 00991263 Operating pressure 0.15 MPa ... 0.8 MPa Operating pressure 1.5 bar ... 8 bar Max. speed 0.8 m/s Repetition accuracy 0.3 mm Mode of operation Double-acting Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature 0 °C ... 60 °C Impact energy in end positions 0.12 J Cushioning length 1.3 mm Max. force Fy 1078 N Max. force Fz 1078 N Max. moment Mx 15 Nm Max. moment My 8 Nm Max. moment Mz 8 Nm Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 51 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 68 N Moving mass 194 g Product weight 487 g alternative connections See product drawing Type of mounting With through-hole Pneumatic connection M5 Note on materials RoHS-compliant Material cover Wrought aluminium alloy Material seals HNBR Material housing Wrought aluminium alloy Material piston rod High-alloy stainless steel
More Information
Manufacturer Nr.
DGSL-10-30-EA
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568216696
Weight
0.550000
HS-Code
84123100
Article authenticity
Original product
Condition of article
New
