Festo 8078873. Mini slide DGST-25-20-E1A
Manufacturer Nr.
DGST-25-20-E1A
Frequently Bought Together
Stroke 20 mm Piston diameter 25 mm Operating mode, drive unit Yoke Cushioning Elastomer cushioning, double-sided, stroke not adjustable Mounting position optional Guide Ball bearing cage guide Design Twin piston
Yoke
Piston rod
Slide Position detection Via proximity switch Symbol 00991249 Operating pressure 0.1 MPa ... 0.8 MPa Operating pressure 1 bar ... 8 bar Operating pressure 14.5 psi ... 116 psi Max. speed 0.5 m/s Repetition accuracy <= 0.3 mm Mode of operation Double-acting Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature -10 °C ... 60 °C Impact energy in end positions 0.3 J Cushioning length 1.2 mm Max. force Fy 1460 N Max. force Fz 1460 N Max. moment Mx 16 Nm Max. moment My 16 Nm Max. moment Mz 16 Nm Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 495 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 589 N Moving mass 738 g Product weight 1528 g Type of mounting With through-hole Pneumatic connection G1/8 Note on materials RoHS-compliant Material cover Wrought aluminium alloy Material seals HNBR Material guide POM
TPE-E
High-alloy steel Material housing Wrought aluminium alloy Material piston rod High-alloy stainless steel
More Information
Manufacturer Nr.
DGST-25-20-E1A
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568447045
Weight
1.500000
HS-Code
84123100
Article authenticity
Original product
Condition of article
New
