Festo 1320781. Bellow gripper DHEB-22-E-D-S-P
Manufacturer Nr.
DHEB-22-E-D-S-P
Frequently Bought Together
Size 22 Stroke of bellows 12 mm Min. ø to be gripped 24 mm Max. ø to be gripped 31.5 mm Mounting position optional Mode of operation Single-acting
Closed Gripper function Adaptive Design Contracting diaphragm
Force pilot operated motion sequence Guide Basic guide Position detection Without Operating pressure 5 bar ... 8 bar Reset pressure 1 bar Max. operating frequency of gripper 4 Hz Min. opening time at 0.6 MPa (6 bar, 87 psi) 30 ms Min. closing time at 0.6 MPa (6 bar, 87 psi) 60 ms Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364 zone III Suitable for use with food See supplementary material information Ambient temperature 5 °C ... 60 °C Average replacement interval for the bellows 1 MioCyc Guide value for effective load 0.32 kg Product weight 43 g Type of mounting Either:
Via male thread
Via lock nut Pneumatic connection M5 Note on materials RoHS-compliant Material bellows VMQ (silicone) Material housing Aluminium
Anodised
More Information
Manufacturer Nr.
DHEB-22-E-D-S-P
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568230012
Weight
0.105000
HS-Code
84798997
Article authenticity
Original product
Condition of article
New
