Festo 153204. Multiple distributor QST3-8-6
Manufacturer Nr.
QST3-8-6
Frequently Bought Together
Size Standard Nominal size 3.6 mm Mounting position optional Design Push-pull principle Size of pack 1 Operating pressure complete temperature range -0.95 bar ... 6 bar Temperature-dependent operating pressure -0.95 bar ... 14 bar Maritime classification See certificate Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Water as per manufacturer's declaration at www.festo.com Note on operating and pilot medium Lubricated operation possible Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature -10 °C ... 80 °C Product weight 23 g Number of outputs 4 Number of supply lines 1 Pneumatic connection, port 1 For tubing outer diameter of 8 mm Pneumatic connection, port 2 For tubing outside diameter of 6 mm Colour of release ring Blue Note on materials RoHS-compliant Material housing PBT Material release ring POM Material tubing seal NBR Material tubing clamp component High-alloy stainless steel
More Information
Manufacturer Nr.
QST3-8-6
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568032883
Weight
0.024000
HS-Code
39174000
Article authenticity
Original product
Condition of article
New
