Festo 153246. Multiple distributor QSLV6-3/8-8
Manufacturer Nr.
QSLV6-3/8-8
Frequently Bought Together
Size Standard Nominal size 4.1 mm Type of seal on screwed plug Coating Mounting position optional Design Push-pull principle Size of pack 1 Operating pressure complete temperature range -0.095 MPa ... 0.6 MPa Operating pressure complete temperature range -0.95 bar ... 6 bar Operating pressure complete temperature range -13.775 psi ... 87 psi Temperature-dependent operating pressure -0.095 MPa ... 1.4 MPa Temperature-dependent operating pressure -0.95 bar ... 14 bar Temperature-dependent operating pressure -13.775 psi ... 203 psi Maritime classification See certificate Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Water as per manufacturer's declaration at www.festo.com Note on operating and pilot medium Lubricated operation possible Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature -10 °C ... 80 °C Nominal torque 15.5 Nm Tolerance for nominal tightening torque ± 20% Product weight 81 g Number of outputs 6 Number of supply lines 1 Pneumatic connection, port 1 Male thread R3/8 Pneumatic connection, port 2 For tubing outside diameter of 8 mm Colour of release ring Blue Note on materials RoHS-compliant Material housing PBT Material hollow bolt Nickel-plated brass Material release ring POM Material tubing seal NBR Material tubing clamp component High-alloy stainless steel
More Information
Manufacturer Nr.
QSLV6-3/8-8
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568033279
Weight
0.080000
HS-Code
74122000
Article authenticity
Original product
Condition of article
New
