Festo 3714. Quick connector ACK-1/8-PK-4
Manufacturer Nr.
ACK-1/8-PK-4
Festo 3714. Quick connector ACK-1/8-PK-4 is available to buy in increments of 10
Frequently Bought Together
Nominal size 3.4 mm Type of seal on screwed plug Sealing ring Mounting position optional Design Straight design Size of pack 10 Operating pressure complete temperature range -0.095 MPa ... 1 MPa Operating pressure complete temperature range -0.95 bar ... 10 bar Operating pressure complete temperature range -13.775 psi ... 145 psi Note on operating pressure Water: max. 0.6 MPa at max. 50°C Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Water (liquid, ice-free) Note on operating and pilot medium Lubricated operation possible
Water: G thread only possible with OL sealing ring Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature -10 °C ... 60 °C Nominal torque 3.5 Nm Tolerance for nominal tightening torque ± 20% Pneumatic connection, port 1 Female thread G1/8 Pneumatic connection, port 2 For tubing outside diameter of 6 mm
For barbed fitting inside diameter of 4 mm with nut Material union nut Wrought aluminium alloy, anodised Material screwed plug Anodised wrought aluminium alloy Note on materials RoHS-compliant Material sealing ring Reinforced PA
TPE-U(PU)
More Information
Manufacturer Nr.
ACK-1/8-PK-4
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568018603
Weight
0.006000
HS-Code
76090000
Article authenticity
Original product
Condition of article
New
