Festo 178290. Proximity sensor SIES-Q5B-NS-K-L
Manufacturer Nr.
SIES-Q5B-NS-K-L
Frequently Bought Together
Conforms to standard EN 60947-5-2 Symbol 00991704 Approval RCM trademark
c UL us listed (OL) CE mark (see declaration of conformity) To EU EMC Directive Rated operating distance 0.8 mm Assured operating distance 0.64 mm Reduction factors Aluminium = 0.4
Stainless steel St 18/8 = 0.7
Copper = 0.3
Brass = 0.4
Steel St 37 = 1.0 Ambient temperature -25 °C ... 70 °C Repetition accuracy 0.04 mm Switching output NPN Switching element function N/O contact Max. switching frequency 3000 Hz Max. switching frequency DC 3000 Hz Max. output current 200 mA Voltage drop 2 V Short circuit current rating Pulsed Operational voltage range DC 10 V ... 30 V Residual ripple 10 % No-load supply current 10 mA Reverse polarity protection For all electrical connections Electrical connection 3-wire
Cable Cable length 2.5 m Material cable sheath TPE-U(PUR) Size 5x5x25 mm Type of mounting Via female thread Mounting type Flush Product weight 22 g Material housing Brass
Nickel-plated Switching status indication Yellow LED Degree of protection IP67 LABS (PWIS) conformity VDMA24364-B2-L Additional information for sensor selection Special design Electrical output NPN Selection of sensor design Standard
More Information
Manufacturer Nr.
SIES-Q5B-NS-K-L
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568075729
Weight
0.036000
HS-Code
85365019
Article authenticity
Original product
Condition of article
New
