Festo 150447. Proximity sensor SIEN-M30NB-PO-S-L
Manufacturer Nr.
SIEN-M30NB-PO-S-L
Frequently Bought Together
Conforms to standard EN 60947-5-2 Symbol 00992830 Approval RCM trademark
c UL us listed (OL) CE mark (see declaration of conformity) To EU EMC Directive Note on materials RoHS-compliant Rated operating distance 15 mm Assured operating distance 12.15 mm Reduction factors Aluminium = 0.5
Stainless steel St 18/8 = 0.85
Copper = 0.43
Brass = 0.53
Steel St 37 = 1.0 Ambient temperature -25 °C ... 70 °C Repetition accuracy 0.75 mm Switching output PNP Switching element function N/C contact Hysteresis 1.65 mm Max. switching frequency 700 Hz Max. output current 200 mA Voltage drop 2 V Short circuit current rating Pulsed Operational voltage range DC 16 V ... 30 V Residual ripple +/- 20 % No-load supply current 10 mA Reverse polarity protection For all electrical connections Electrical connection 3-pin
M12x1
Plugs Size M30x1.5 Type of mounting Via lock nut Tightening torque 40 Nm Mounting type Not flush Product weight 100 g Material housing Brass
PA
PBTP
Chrome-plated Switching status indication Yellow LED Ambient temperature with moving cable -5 °C ... 70 °C Degree of protection IP67 Immunity to surge 0.8 kV LABS (PWIS) conformity VDMA24364-B2-L Pollution degree 3 Additional information for sensor selection with standard sensing distance Electrical output PNP Selection of sensor design Standard
More Information
Manufacturer Nr.
SIEN-M30NB-PO-S-L
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568069575
Weight
0.120000
HS-Code
85365019
Article authenticity
Original product
Condition of article
New
